SounDigital 2400.1-4 EVOPS 4ohm
EAN: 7898644526146
SD2400.1-4 EVOPS
Mono amplifier
2400W
IP64 rating
Splash waterproof
4 Ohm model
Läs Mera
1 st
IP64 Rating
7 990,00 kr
Beskrivning
Teknisk information
Bruksanvisningar
For use in Power Sports projects, the 2400.1 EVOPS is a compact, modern design amplifier that delivers 2400W RSM of power distributed over 1 channel. The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for projects in water, clay and other Power Sports settings.
Power @ 1Ω: N/A
Power @ 2Ω: N/A
Power @ 4Ω: 1 x 2400 WRMS
Power @ 8Ω: 1 x 1584 WRMS
Operating Voltage:
8V – 16V
Current Draw (Music):
93A
Current Draw (Max):
185A
Recommended Fuse (Music):
100A
Total Efficiency:
90%
Damping Factor:
2000
Frequency Response (-3dB):
5Hz – 25kHz
SNR:
90dB
Crossover LPF:
50Hz – 500Hz
Subsonic:
5Hz – 40Hz
Bass Boost:
50 Hz fix - 0 to +12dB
Width:
5.8 in / 14,9 cm
Length:
8.4 in / 21,4 cm
Height:
2.3 in / 6 cm.
Power @ 2Ω: N/A
Power @ 4Ω: 1 x 2400 WRMS
Power @ 8Ω: 1 x 1584 WRMS
Operating Voltage:
8V – 16V
Current Draw (Music):
93A
Current Draw (Max):
185A
Recommended Fuse (Music):
100A
Total Efficiency:
90%
Damping Factor:
2000
Frequency Response (-3dB):
5Hz – 25kHz
SNR:
90dB
Crossover LPF:
50Hz – 500Hz
Subsonic:
5Hz – 40Hz
Bass Boost:
50 Hz fix - 0 to +12dB
Width:
5.8 in / 14,9 cm
Length:
8.4 in / 21,4 cm
Height:
2.3 in / 6 cm.
