DD Audio ZVL Multi-Amp Sync Module
ZVL
DD Audio link module
Läs Mera
1 790,00 kr
Beskrivning
Teknisk information
Bruksanvisningar
The ZVL is a multi amplifier synching module designed to allow a user to link, strap, and tune the preamps of multiple amplifiers from a single module for precisions control of large mobile audio systems. The ZVL was designed to work seamlessly with the new M Series amplifier’s ZVL INPUT, but it is universally compatible and will work with the DD Audio DM Series as well as other brands of Amplifiers.
You can also Link Multiple ZVL Units Together if needed!
- Link and Control Multiple Amplifiers
- Strap and Control Multiple Amplifiers
- Active RCA Signal Distribution
- Compatible with All Amplifiers
- Link Multiple ZVL Units Together
You can also Link Multiple ZVL Units Together if needed!
- Link and Control Multiple Amplifiers
- Strap and Control Multiple Amplifiers
- Active RCA Signal Distribution
- Compatible with All Amplifiers
- Link Multiple ZVL Units Together
Operating Voltage: 9 - 16
Input Channels: 2
Output Channels: 10
Max Current Draw (Amps): 200mA
RCA Input Sensitivity (Volts): 0.2 - 8
RCA Output Voltage (Volts): 8
Frequency Response: 10 - 25k
RCA Input S/N: ≥ 105dBA
THD: 0.2%
RCA Input Impedance: 20k
RCA Output Impedance: ≥ 100
Remote Out Current: 500mA @ 12V
Low Pass Filter: 20 - 200
Sub Sonic Filter: 10 - 50
Dimensions (Inches): 4 x 5 x 2
Dimensions (MM): 98 x 125 x 47.
Input Channels: 2
Output Channels: 10
Max Current Draw (Amps): 200mA
RCA Input Sensitivity (Volts): 0.2 - 8
RCA Output Voltage (Volts): 8
Frequency Response: 10 - 25k
RCA Input S/N: ≥ 105dBA
THD: 0.2%
RCA Input Impedance: 20k
RCA Output Impedance: ≥ 100
Remote Out Current: 500mA @ 12V
Low Pass Filter: 20 - 200
Sub Sonic Filter: 10 - 50
Dimensions (Inches): 4 x 5 x 2
Dimensions (MM): 98 x 125 x 47.
