SounDigital 1200.1 EVO 5 - 1 Ohm
EAN: 7898644525286
SD1200.1-1 EVO5
Mono amplifier
1 Ohm model
1200W
Very small size
High level input
Läs Mera
1 st
2 490,00 kr
Beskrivning
Teknisk information
The 1200.1 EVO 5 is a compact, modern amplifier that delivers 1200W RMS of power over 1 channel.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.
The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.
Power @ 4Ω: 1 X 522 WRMS
Power @ 2Ω: 1 X 792 WRMS
Power @ 1Ω: 1 X 1200 WRMS
Frequency Response (-3dB):
5Hz ~ 25kHz
Subsonic Filter:
5Hz ~ 80Hz
Low Pass Filter:
50Hz ~ 1kHz
Bass Boost:
0dB ~ 12dB @ 50Hz
Operating Voltage:
9V ~ 16V
Signal-Noise Ratio:
95dB
Input Sensitivity:
0.2V ~ 2V
Current Draw (Music):
1Ω: 54A
2Ω: 52A
Current Draw (Max):
1Ω: 108A
2Ω: 105A
Total Efficiency:
1Ω: 88%
2Ω: 91%
Damping Factor:
2000
Power Cable:
16mm² (5 AWG)
Audio Output Cable:
1Ω: 2 x 4 mm² (6 AWG)
2Ω: 2 x 2,5 mm² (13 AWG)
Recommended Fuse (Music):
70A
Recommended Battery:
70Ah
Width:
13.6 cm / 5.4 in
Length:
18 cm / 7.1 in
Height:
5.48 cm / 2.1 in
Weight:
1.12 Kg.
