DD Audio SA500
SA500
Micro size mono amplifier
1 x 500W RMS @1ohm
Remote Included in Box
Läs Mera
1 st
1 390,00 kr
Beskrivning
Teknisk information
Bruksanvisningar
The SA500 is the first Micro Monoblock in DD’s new SA (Small Architecture) Series, and it packs over 500 Watts of continuous, pristine power at 1Ω to drive your system with clear, distortion free sound from a micro-chassis.
Utilizing exclusive, discrete transistors, rugged Mosfets, oversized caps, transformers, and other high-grade components, these micro-sized pocket rockets have been engineered to be high speed, full range amps with variable high-pass and low-pass filters, enabling specific band-pass filters to deliver serious power for ANY application. They feature on board hi-level inputs and fit just about anywhere, making the SA500 a simple, time saving, space saving solution for adding smooth bass to your ride.
Utilizing exclusive, discrete transistors, rugged Mosfets, oversized caps, transformers, and other high-grade components, these micro-sized pocket rockets have been engineered to be high speed, full range amps with variable high-pass and low-pass filters, enabling specific band-pass filters to deliver serious power for ANY application. They feature on board hi-level inputs and fit just about anywhere, making the SA500 a simple, time saving, space saving solution for adding smooth bass to your ride.
Operating Voltage: 9 - 16
Test Voltage: 14.4
Input Channel(s): 2
Output Channel(s): 1
Continuous Wattage @4ohm: 200
Continuous Wattage @2ohm: 325
Continuous Wattage @1ohm: 500
Max Current Draw (Amps): 50
RCA Input Voltage Sensitivity: 6 - 0.25
High-Level Input Voltage Sensitivity: 20 - 1.1
RCA Input S/N: 95
Damping Factor: 100
THD: 1.0%
Bass Boost: 12
Frequency Response (Hz): 30 - 20k
Sub-Sonic Filter: 20 - 80
Low-Pass Filter: 40 - 20k
Remote Control: Remote Included in Box
Power Wire Gauge: 8
Speaker Wire Gauge: 8
Dimensions (Inches): 4.8 x 3.2 x 1.7
Dimensions (MM): 121 x 81 x 43
Test Voltage: 14.4
Input Channel(s): 2
Output Channel(s): 1
Continuous Wattage @4ohm: 200
Continuous Wattage @2ohm: 325
Continuous Wattage @1ohm: 500
Max Current Draw (Amps): 50
RCA Input Voltage Sensitivity: 6 - 0.25
High-Level Input Voltage Sensitivity: 20 - 1.1
RCA Input S/N: 95
Damping Factor: 100
THD: 1.0%
Bass Boost: 12
Frequency Response (Hz): 30 - 20k
Sub-Sonic Filter: 20 - 80
Low-Pass Filter: 40 - 20k
Remote Control: Remote Included in Box
Power Wire Gauge: 8
Speaker Wire Gauge: 8
Dimensions (Inches): 4.8 x 3.2 x 1.7
Dimensions (MM): 121 x 81 x 43
