Ground Zero GZNT 28SQ
EAN: 4037072023848
GZNT 28SQ
28mm / 1.10″
Silk dome
140W
Neodymium motor
Läs Mera
par
2 490,00 kr
Beskrivning
Teknisk information
Bruksanvisningar
1.1″ high performance silk dome tweeter with coupled chamber
28 mm / 1.1″ high performance tweeter
Coated silk dome
High power capable copper voice coil
Anodyzed aluminum housing
Damped coupled chamber
Neodymium motor
Gold plated screw terminal
1 pair / package
28 mm / 1.1″ high performance tweeter
Coated silk dome
High power capable copper voice coil
Anodyzed aluminum housing
Damped coupled chamber
Neodymium motor
Gold plated screw terminal
1 pair / package
Model
High-Performance tweeter
Diameter
28 mm / 1.10″
Power Handling (RMS/max.)
90 / 140 Watts
Impedance
4 Ohms
Efficiency
91 dB
Frequency Response
2000 Hz – 25 kHz
Empfohlener Hochpass-Filter
3000 Hz @ 12 dB/oct
Voice Coil
28 mm / 1.1″
Membran Layout
Coated silk dome
Magnet material
Neodymium
Mounting Ø
48 mm / 0.19″
Mounting Depth
29 mm / 1.14″
Resonance Frequency (Fs)
1350 Hz.
High-Performance tweeter
Diameter
28 mm / 1.10″
Power Handling (RMS/max.)
90 / 140 Watts
Impedance
4 Ohms
Efficiency
91 dB
Frequency Response
2000 Hz – 25 kHz
Empfohlener Hochpass-Filter
3000 Hz @ 12 dB/oct
Voice Coil
28 mm / 1.1″
Membran Layout
Coated silk dome
Magnet material
Neodymium
Mounting Ø
48 mm / 0.19″
Mounting Depth
29 mm / 1.14″
Resonance Frequency (Fs)
1350 Hz.
