DD Audio 3510G ESP D2 SuperCharged

DD3510G-D2.0-SUPER

Digital Designs 3510 DVC 2 10“ Subwoofer

Läs Mera
7 990,00 kr
Vikt: 16.00 kg
Beställningsvara
Frågor? Kontakta ossinfo(at)audioimport.fi
Beskrivning
Teknisk information
The 3500s are some of our most sonically accurate sub-drivers. This accuracy comes from a low moving mass, ultra high energy design that uses a crazy strong motor with a highly focused voice coil gap. 3500 Series subs come with EROM or V-ROM surrounds, multi-layer spiders, 800-degree thermoset voice coils, and cast aluminum frames. All of these features combine to make the 3500 Series a brutally musical addition to our USA built lineup. The 3500 Series features our Evolution Subwoofer Package (ESP). ESP equipped drivers sport a deeper frame than standard subs and an exclusive surround and cone designs. ESP subs are truly built to maximize performance in their designated size class. The 3500 Series comes standard with an oversized dry finish black composite dust cap, red logo, and treated pulp cone, but it can be optioned out with alternative composite dust caps, composite cones, powder coated frames, supercharging, and a multitude of logo options to give your sub a personalized look and/or added performance for a specific application.
MODEL3510 (ESP)
Driver Size - in10
Power Band - Watts600 - 1200
Burst Power - Watts4800
VCD - in3
ImpedanceD2
Piston Dia - in 9.25
Fs - Hz 41.72
Qms 6.607
Qes0.532
Qts0.492
Vas - cu ft 0.534
Xmech - mm80
Xmax - mm17
Cutout Diameter - in10.187
Mounting Depth - in7.5
Motor Diameter - in7.687
Driver Displacement - cu ft0.12
Shipping Weight - lbs37
Sealed Enclosure - cu ftN/A
Ported Enclosure - cu ft1.25 - 1.75.
